Metric / inch size available
Stainless steel sleeve anchors and special length sleeve anchors available
The sleeve anchors allow it to anchor into concrete, brick and block. Sleeve anchors work when you insert it into a predrilled hole in the base material and then turn the nut to pull the working end of the sleeve anchor up through the sleeve. The anchor is then expanded and anchored securely in the concrete, brick or block. The anchors are available in zinc plated and stainless steel. Sleeve anchors come fully assembled and ready to use.
Other Used Names
Sleeve thunderbolts, bolt sleeve anchors, masonry anchors
Dia.X Length | Max. Fixture Thickness (mm) | Pull out Load (Kgs) |
M6.5X18 | 3 | 800 |
M6.5X25 | 4 | |
M6.5X36 | 8 | |
M6.5X56 | 26 | |
M6.5X75 | 45 | |
M8X40 | 8 | 1200 |
M8X65 | 35 | |
M8X85 | 55 | |
M10X40 | 6 | 1700 |
M10X50 | 12 | |
M10X60 | 15 | |
M10X75 | 27 | |
M10X100 | 62 | |
M12X60 | 15 | 2500 |
M12X75 | 27 | |
M12X100 | 52 | |
M12X120 | 70 | |
M12X130 | 80 | |
M16X65 | 20 | 3700 |
M16X110 | 65 | |
M16X145 | 100 | |
M20X75 | 25 | 5100 |
M20X107 | 57 | |
M20X151 | 101 |
Dia.X Length | Max. Fixture Thickness (mm) | Pull out Load (Kgs) |
1/4X1-3/8 | 1" | 1200 |
1/4X2-1/4 | 1" | |
1/4X3 | 1" | |
1/4X4 | 1" | |
5/16X1-1/2 | 1" | 1700 |
5/16X2-1/2 | 1" | |
3/8X1-7/8 | 1-1/4" | 2700 |
3/8X3 | 1-1/4" | |
3/8X4 | 1-1/4" | |
3/8X5 | 1-1/4" | |
3/8X6 | 1-1/4" | |
1/2X2-1/4 | 1-1/2" | 4300 |
1/2X3 | 1-1/2" | |
1/2X4 | 1-1/2" | |
1/2X6 | 1-1/2" | |
5/8X2-1/4 | 2" | 6100 |
5/8X3 | 2" | |
5/8X4-1/4 | 2" | |
5/8X5-3/4 | 2" | |
5/8X6 | 2" | |
3/4X2-1/2 | 2" | 7800 |
3/4X4-1/4 | 2" | |
3/4X5-1/2 | 2" | |
3/4X6-1/4 | 2" |
