Drop In Anchor

Thread Size(A)

Anchor Dia.(B)

Thread Depth
 (D)

Anchor Length (C)

Pull out Load (Kgs)

Qty.Per Box/Ctn

Weight Kgs/
 1000pcs

1/4-20

3/8"

1/2"

1"

1000

100/2000

11.0

3/8-16

1/2"

5/8"

1-9/16"

2000

50/1000

28.0

1/2-13

5/8"

3/4"

2"

3200

50/500

54.0

5/8-11

7/8"

7/8"

2-1/2"

5400

25/200

141.0

3/4-10

1"

1-1/4"

3-1/8"

7000

25/150

227.0

M6 (W1/4)

8.0

10

25

950

100/2000

6.3

M8 (W5/16)

10.0

14

30

1350

100/2000

12.5

M10 (W3/8)

12.0

15

40

1950

50/1000

25.0

M12 (W1/2)

16.0

20

50

2900

50/500

51.0

M16 (W5/8)

20.0

25

65

4850

25/200

112.0

M20 (W3/4)

25.0

35

80

5900

25/150

235.0
